Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures
Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures
Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures
ﺎﺘﺼﻟ ﺍﻶﻧ

Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures

الحد الأدنى لكمية : 1pc الأسعار : Negotiated
تفاصيل التغليف : مربع كمتطلبات وقت التسليم : 20-30 يوم
شروط الدفع : T/T ، Western Union ، L/C القدرة على العرض : 1000pc/شهر
مكان المنشأ: صنع في الصين اسم العلامة التجارية: JR
إصدار الشهادات: ISO9001 رقم الموديل: US4A

معلومات تفصيلية
مادة: كذا كذا FKM وظيفة: لمضخة الزيت ، مضخة المياه
حزمة النقل: صندوق رمز HS: 848420090
مواصفة: الختم الميكانيكي Us4a شهادة: ISO9001
يكتب: فلويتين الختم الميكانيكي Us4a معيار: معيار
مقاس: 20،48،65،80،90،100mm اسم: Us4a

منتوج وصف

Mechanical Seal Dw3 Shaft Seal Sic/Car Epdm La2359304 For Apv Pumps


Description:


  1. High Quality Mechanical Seals
    Description:

    Heavy duty solution for low and medium pressures operations are widely used in the chemical industry and waterworks.
    The US4A is the short version of US3A, single component seal with a type A pinned stationary seat and it.
    Allows rotation in two directions.
    Because of the three drive lugs on the rotating body, they can tolerate high levels of vibration, and mechanical stress.
    The O-ring is easily removed and refitted when assembling the seal on shafts with keyways, threads or sharp edges.
    The US4A version in supplied with a single spring and is more suitable for moderately dirty liquids.

2. Materials:

  • Gaskets in either nitrile, EPDM or Viton rubber
    The slide ring is in carbon, silicon or tungsten
    The seat is made of silicon or tungsten
  • 3. Seat Type:
  • 4. Applications: Clean water, sewage water, oil and other moderately corrosive fluids


Performance Capabilities:


Temperature
-20℃ to 180℃, dependent on the elastomer
Pressure
Up to 10 bar
Speed
Up to 15 m/s
End play/axial float allowance
±0.1mm
Size
20mm-100mm
Brand
JR
Face
Carbon, SiC, TC
Seat
Ceramic, SiC, TC
Elastomer
NBR, EPDM, FKM etc.
Spring
SS304, SS316
Metal parts
SS304, SS316
Idividual Packing
Using foam and plastic paper wrapped, then put one piece of seal in one box,finally put in standard export carton.

Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures 0

Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures 1Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures 2Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures 3Fluliten Mechanical Seal Us4a Heavy Duty Solution For Low And Medium Pressures 4



We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,



All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.



At the meantime, we could manufacture seals according to your sample or drawing, and design as your request
